Wire rope sheave mainly consists of the following key structural parts:
1. Wheel body
Body shape: The wheel body is usually circular, and its circumference is designed to ensure that the wire rope can rotate smoothly around it. The size of the wheel body varies according to the specific application scenario and load requirements.
Rope groove structure: The rope groove is the most important part of the wheel surface. The common shapes of the rope groove are U-shaped and V-shaped. The bottom of the U-shaped rope groove is relatively round, which can make the wire rope fit better in the groove, and the extrusion and wear of the wire rope are relatively small. The V-shaped rope groove has better anti-rope derailment performance, and the inclination angles on both sides can effectively limit the lateral movement of the wire rope. The depth and width of the rope groove need to be determined according to the diameter of the wire rope. Generally, the wire rope is required to have a suitable embedding depth in the rope groove to ensure that it will not easily jump out of the rope groove during operation.
Material characteristics: The sheave is mostly made of metal, such as cast iron, cast steel or forged alloy steel. Cast iron sheaves are relatively inexpensive and suitable for applications with smaller loads and relatively good working environments. Cast steel sheaves are stronger and tougher than cast iron, and can withstand greater loads and impacts, and are often used in medium-sized lifting equipment. Forged alloy steel sheaves have the highest strength and wear resistance, and are used in large, heavy-duty port or mining lifting equipment and other applications that require extremely high pulley performance.
2. Wheel hub
Connection function: The hub is located at the center of the wheel body and is the key part connecting the wheel body and the shaft. It is usually connected to the shaft through a keyway or spline to ensure that the pulley can rotate synchronously with the shaft. In some high-precision equipment, precision bearings such as tapered roller bearings or deep groove ball bearings are also installed between the hub and the shaft to reduce friction resistance during rotation and improve the rotation efficiency of the pulley.
Size fit: The size of the hub, including the inner diameter, outer diameter and length, needs to match the size of the shaft and the overall design of the pulley. Its inner diameter should be closely matched with the outer diameter of the shaft to ensure the stability of the connection; the outer diameter and length should take into account factors such as bearing installation and load capacity.
3. Side panels (rims)
Anti-slip function: The side plates are also called wheel rims and are located on both sides of the wheel body. Their main function is to prevent the wire rope from slipping out of the two sides of the pulley during operation. The height of the side plates is determined according to the diameter of the wire rope and the working environment of the pulley. In some multi-layer winding application scenarios, the height of the side plates will be increased accordingly, and a special guide device may be designed on the inside to guide the wire rope to be wound in multiple layers in an orderly manner.
Structural strength: The thickness and strength of the side panels should be designed to withstand the lateral force that may be generated by the wire rope during operation. In some cases of high-speed operation or high wire rope tension, the side panels need to be strong enough to prevent deformation and ensure the normal operation of the pulley.
